Stringing Equipment For Overhead Power Lines Groove Number 2x12

Stringing Equipment For Overhead Power Lines Groove Number 2x12
Stringing Equipment For Overhead Power Lines Groove Number 2x12
Stringing Equipment For Overhead Power Lines Groove Number 2x12 Stringing Equipment For Overhead Power Lines Groove Number 2x12 Stringing Equipment For Overhead Power Lines Groove Number 2x12

Large Image :  Stringing Equipment For Overhead Power Lines Groove Number 2x12

Product Details:
Place of Origin: CHINA
Brand Name: GALAXY
Certification: CE,ISO
Model Number: GL2X80
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: Negotiable
Packaging Details: CARTON
Delivery Time: 45 days
Payment Terms: L/C, T/T
Supply Ability: 15 sets per month
Contact Now

Stringing Equipment For Overhead Power Lines Groove Number 2x12

Description
Type: Stringing Equipment Hydraulic Tensioner Hydraulic Pump: German Rexroth/Dnish Danfoss
Max Tension: 2x80kN Pull At Max Speed: 2x40kN
Bull-wheel Diameter: 1300/1500mm Overall Dimension (length*width*height): 5500×2300×2600mm
High Light:

powerline construction tools

,

transmission line stringing tools

Stringing Equipment For Overhead Power Lines Groove Number 2x12



Characteristics
  • Bull-wheel diameter: 1300/1500mm
  • Groove number: 2x12
  • Max conductor diameter: 35mm
  • Total weight: 9000kg
  • Overall dimension (length*width*height):5500×2300×2600mm
Performance
  • Max tension: 2x80kN
  • Speed at max tension: 2.5km/h
  • Max speed: 5km/h
  • Pull at max speed: 2x40kN
  • Max reverse pulling force: 2x60kN
  • Max reverse pulling speed: 2km/h
Main configuration
  • Engine: Cummins
  • Hydraulic pump: German Rexroth/Dnish Danfoss
  • Main motor:German Rexroth/French Leduc
  • Speed reducer: German Rexroth/Italy Bonfiglioli
  • Hydraulic meter: German
  • Operating handle: German Rexroth
  • Main valve: German Rexroth/US Sun/Italy Atos
Engine
  • Diesel: 97kw(130hp)
  • Cooling system: water
  • Electrical system: 24V
Hydraulic Transmission
  • The machine can realize step less speed.
  • The machine is provided with tension presetting system.
Configuration
  • 2 negative self-acting hydraulic brakes
  • 2 hydraulic dynamometers
  • Hydraulic oil cooling system
  • 2 digital meter counters
  • 2 digital speed meters
  • Control instruments for hydraulic system and diesel engine
  • Rigid axle for towing at max speed of 30km/h with mechanical parking brake
  • Hydraulic power pack to control up to 6 separate drum stands with hydraulic motor
  • Grounding connection point
Additional Devices
  • Lighting system for the trailer
  • 6 hydraulic rope/conductor clamp (extra charge)
  • Swivel guide rope roller
  • Trailer for towing at max speed of 30 km/h
  • Digital speed and meter counter
  • Air brake system for the trailer (extra charge)



Stringing Equipment For Overhead Power Lines Groove Number 2x12 0

Stringing Equipment For Overhead Power Lines Groove Number 2x12 1
