Durable GP100 Underground Cable Equipment Yanmar Japan 49.2hp Puller

Durable GP100 Underground Cable Equipment Yanmar Japan 49.2hp Puller
Durable GP100 Underground Cable Equipment Yanmar Japan 49.2hp Puller Durable GP100 Underground Cable Equipment Yanmar Japan 49.2hp Puller

Large Image :  Durable GP100 Underground Cable Equipment Yanmar Japan 49.2hp Puller

Product Details:
Place of Origin: China
Brand Name: GALAXY
Certification: ISO9001
Model Number: GP100
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Carton
Delivery Time: 10-30days
Payment Terms: L/C, T/T
Supply Ability: 200 sets per month

Durable GP100 Underground Cable Equipment Yanmar Japan 49.2hp Puller

Description
Max Pull Force: 100kN Diesel: Yanmar Japan 49.2hp/36kw
Type: Underground Cable Pulling Machine Engine: Yanmar Japan
Hydraulic Motor: Rexroth German Overall Dimension (length*width*height): 4000*2200*1800mm
High Light:

pulling machine equipment

,

electric wire pulling equipment



GP100 Underground Cable Equipment Yanmar Japan 49.2hp Puller



Performance

  • Model: GP100
  • Max pull force: 100kN
  • Maximum cable diameter:80 mm
  • Max speed at Continuous pull: 17m/min
  • Pull at max speed: 15kN
  • Max speed: 83m/min
  • Total weight: 3350kg
  • Capstans: 350x650mm
  • Continuous pull effort: 80kN
  • Overall dimension (length*width*height): 4000*2200*1800mm

Main Configuration

  • Engine: Yanmar Japan
  • Hydraulic motor: Rexroth German
  • Hydraulic pump: Danfoss
  • Hydraulic meter: German
  • Operating handle: Bondioli & Pavesi Italy
  • Hydraulic valve: Sun USA

Engine

  • Diesel: Yanmar Japan 49.2hp/36kw
  • Cooling system water
  • Electrical system 12V

Configuration

  • Control panel with instruments for hydraulic system and engine.
  • A dynamometer used to check pull values
  • Mechanical front and rear stabilizer
  • Grounding connection point
  • Large channel steel capstan with anti-skid device
  • Hydraulic oil cooling system
  • In the case of over pull, the preset for maximum tension can stop the puller
  • The hydrostatic loop, which allows the puller to continue to change speed in two rotational modes, can operate only one command
  • Hydraulic emergency brake operates automatically at the center of the instruction bar or in the case of hydraulic failure (not suitable for lifting)

Additional Devices

Swivel guide rope roller

Lighting system for the trailer
Digital speed and meter counter (extra charge)
Chassis, with damping shaft, tires, traction lever, Trailer for towing at max speed of 30 km/h
Accessories for anchoring and lifting

The heat exchanger cools the oil in the hydraulic circuit

Rear tension roller with hydraulic drive



Durable GP100 Underground Cable Equipment Yanmar Japan 49.2hp Puller 0
